This is the part 3 of the Exploring Delphi XE3 – WinApi Additions – Winapi.Functiondiscovery Article.

The Function Discovery API can be used not just for enumerate devices also you can receive notifications as well, like when a device is added, removed or a property of the device is modified. In order to receive such notifications you must implement the IFunctionDiscoveryNotification interface and pass a instance of this implementation to the CreateInstanceCollectionQuery method, then you must restrict the result of the query with the method AddQueryConstraint passing the PROVIDERPNP_QUERYCONSTRAINT_NOTIFICATIONSONLY value to only receive notifications and finally call the IFunctionInstanceCollectionQuery.Execute method.

Implementing the IFunctionDiscoveryNotification interface

The IFunctionDiscoveryNotification interface exposes 3 methods to receive the results of the asynchronous queries returned by the execution of the IFunctionInstanceCollectionQuery.Execute method.

This is the Delphi declaration of the IFunctionDiscoveryNotification interface.

IFunctionDiscoveryNotification = interface(IUnknown)
[SID_IFunctionDiscoveryNotification]
  function OnUpdate(enumQueryUpdateAction: QueryUpdateAction; fdqcQueryContext: FDQUERYCONTEXT; pIFunctionInstance: IFunctionInstance): HRESULT; stdcall;
  function OnError(hr: HRESULT; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT; stdcall;
  function OnEvent(dwEventID: DWORD; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT; stdcall;
end;

Now check this Delphi implementation for the IFunctionDiscoveryNotification interface.

type
  TFunctionDiscoveryOnUpdate = procedure(enumQueryUpdateAction: QueryUpdateAction; fdqcQueryContext: FDQUERYCONTEXT;
      pIFunctionInstance: IFunctionInstance) of object;
  TFunctionDiscoveryOnError  = procedure(hr: HRESULT; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR) of object;
  TFunctionDiscoveryOnEvent  = procedure(dwEventID: DWORD; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR) of object;

  TFunctionDiscoveryNotificationSync=class(TInterfacedObject, IFunctionDiscoveryNotification)
  private
    FAction        : QueryUpdateAction;
    FEventAdd      : TEvent;
    FEventRemove   : TEvent;
    FEventChange   : TEvent;
    FOnUpdateEvent : TFunctionDiscoveryOnUpdate;
    FOnErrorEvent  : TFunctionDiscoveryOnError;
    FOnEventEvent  : TFunctionDiscoveryOnEvent;
    function OnUpdate(enumQueryUpdateAction: QueryUpdateAction; fdqcQueryContext: FDQUERYCONTEXT;
      pIFunctionInstance: IFunctionInstance): HRESULT; stdcall;
    function OnError(hr: HRESULT; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT; stdcall;
    function OnEvent(dwEventID: DWORD; fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT; stdcall;
  public
    constructor Create;
    destructor Destroy; override;
    function WaitFor(dwTimeout : DWORD; pszCategory: PWCHAR; eAction : QueryUpdateAction) : HRESULT;
    property OnUpdateEvent: TFunctionDiscoveryOnUpdate read FOnUpdateEvent write FOnUpdateEvent;
    property OnErrorEvent : TFunctionDiscoveryOnError read FOnErrorEvent write FOnErrorEvent;
    property OnEventEvent : TFunctionDiscoveryOnEvent read FOnEventEvent write FOnEventEvent;
  end;


{TFunctionDiscoveryNotificationSync}

constructor TFunctionDiscoveryNotificationSync.Create;
begin
  inherited;
  FOnUpdateEvent:=nil;
  //create the  events objects
  FEventAdd    := TEvent.Create(nil, False, False, '', true);
  FEventRemove := TEvent.Create(nil, False, False, '', true);
  FEventChange := TEvent.Create(nil, False, False, '', true);
end;

destructor TFunctionDiscoveryNotificationSync.Destroy;
begin
  //release the event objects
  FEventAdd.Free;
  FEventRemove.Free;
  FEventChange.Free;
  inherited;
end;

function TFunctionDiscoveryNotificationSync.OnError(hr: HRESULT;
  fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT;
begin
   //send the error notification if a callback method  was defined
   if @FOnErrorEvent<>nil then
    FOnErrorEvent(hr, fdqcQueryContext, pszProvider);
   Exit(S_OK);
end;

function TFunctionDiscoveryNotificationSync.OnEvent(dwEventID: DWORD;
  fdqcQueryContext: FDQUERYCONTEXT; pszProvider: PWCHAR): HRESULT;
begin
   //send the OnEvent notification if a callback method  was defined
   if @FOnEventEvent<>nil then
    FOnEventEvent(dwEventID, fdqcQueryContext, pszProvider);
   Exit(S_OK);
end;

function TFunctionDiscoveryNotificationSync.OnUpdate(
  enumQueryUpdateAction: QueryUpdateAction; fdqcQueryContext: FDQUERYCONTEXT;
  pIFunctionInstance: IFunctionInstance): HRESULT;
begin

    //signal the event object
    case enumQueryUpdateAction of
      QUA_ADD    : FEventAdd.SetEvent;
      QUA_REMOVE : FEventRemove.SetEvent;
      QUA_CHANGE : FEventChange.SetEvent;
    end;

   //send the OnEvent notification if a callback method  was defined
   if (@FOnUpdateEvent<>nil) and (FAction=enumQueryUpdateAction) then
    FOnUpdateEvent(enumQueryUpdateAction, fdqcQueryContext, pIFunctionInstance);
   Exit(S_OK);
end;

function TFunctionDiscoveryNotificationSync.WaitFor(dwTimeout : DWORD; pszCategory: PWCHAR; eAction : QueryUpdateAction) : HRESULT;
var
 hr : HRESULT;
 LEvent : TEvent;
 LWaitResult : TWaitResult;
 FFunctionDiscovery : IFunctionDiscovery;
 ppIFunctionInstanceCollection: IFunctionInstanceCollection;
 ppIFunctionInstanceCollectionQuery: IFunctionInstanceCollectionQuery;
begin
 FAction:=eAction;
 //reset the event objects
 FEventAdd.ResetEvent;
 FEventRemove.ResetEvent;
 FEventChange.ResetEvent;

 //create a instance to the IFunctionDiscovery
 FFunctionDiscovery := CreateComObject(CLSID_FunctionDiscovery) as IFunctionDiscovery;
 //create a new query passing the current class as callback
 hr := FFunctionDiscovery.CreateInstanceCollectionQuery(FCTN_CATEGORY_PNP, nil, true, Self, nil, ppIFunctionInstanceCollectionQuery);

 //instruct to the query to only receive notifications
 if hr=S_OK then
   hr := ppIFunctionInstanceCollectionQuery.AddQueryConstraint(PROVIDERPNP_QUERYCONSTRAINT_NOTIFICATIONSONLY,'TRUE');

 //execute the query
 if hr=S_OK then
   hr := ppIFunctionInstanceCollectionQuery.Execute(ppIFunctionInstanceCollection);

 if( hr=E_PENDING) then hr := S_OK;

    case eAction of
      QUA_ADD    : LEvent:=FEventAdd;
      QUA_REMOVE : LEvent:=FEventRemove;
      QUA_CHANGE : LEvent:=FEventChange;
      else
      LEvent := nil;
    end;

  if (hr=S_OK) and (LEvent<>nil) then
   LWaitResult:= LEvent.WaitFor(dwTimeout);

 // One device may correspond to multiple function instances
 // This sleep allows the OnUpdate call to output information
 // about each Function Instance.
 // THIS SLEEP IS MERELY FOR DISPLAY PURPOSES
 Sleep(1000);
 Exit(hr);
end;

Demo Application

Now using the above implementation we can receive notification about the devices, you can test the next sample app inserting a USB device and then removing.

type
 TNotifier=class
    procedure  OnUpdate(enumQueryUpdateAction: QueryUpdateAction; fdqcQueryContext: FDQUERYCONTEXT;
      pIFunctionInstance: IFunctionInstance);
  end;

procedure NotificationDemo;
Const
  Timeout = 20000;
var
  hr : HResult;
  pIFunctionDiscoveryNotification : TFunctionDiscoveryNotificationSync;
  LNotifier : TNotifier;
begin
 LNotifier:=TNotifier.Create;
 try
   pIFunctionDiscoveryNotification:=TFunctionDiscoveryNotificationSync.Create;
   try
       //set the callback
       pIFunctionDiscoveryNotification.OnUpdateEvent:=LNotifier.OnUpdate;
       Writeln(Format('Waiting for %d ms, to plug in a PnP device',[Timeout]));
       pIFunctionDiscoveryNotification.WaitFor(Timeout, FCTN_CATEGORY_PNP, QUA_ADD);
       Writeln('Done');
   finally
     pIFunctionDiscoveryNotification:=nil;
   end;

   pIFunctionDiscoveryNotification:=TFunctionDiscoveryNotificationSync.Create;
   try
       //set the callback
       pIFunctionDiscoveryNotification.OnUpdateEvent:=LNotifier.OnUpdate;
       Writeln(Format('Waiting for %d ms, to remove a PnP device',[Timeout]));
       pIFunctionDiscoveryNotification.WaitFor(Timeout, FCTN_CATEGORY_PNP, QUA_REMOVE);
       Writeln('Done');
   finally
     pIFunctionDiscoveryNotification:=nil;
   end;
 finally
     LNotifier.Free;
 end;
end;

{ TNotifier }
procedure TNotifier.OnUpdate(enumQueryUpdateAction: QueryUpdateAction;
  fdqcQueryContext: FDQUERYCONTEXT; pIFunctionInstance: IFunctionInstance);
var
  ppIPropertyStore  : IPropertyStore;
  pv : TPropVariant;
begin
  case enumQueryUpdateAction of
    QUA_ADD    : Writeln(Format('Action : %s',['Add']));
    QUA_REMOVE : Writeln(Format('Action : %s',['Remove']));
    QUA_CHANGE : Writeln(Format('Action : %s',['Change']));
  end;
  if Succeeded(pIFunctionInstance.OpenPropertyStore(STGM_READ, ppIPropertyStore)) then
    if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_DeviceDesc, pv)) then
      Writeln(Format('Device Desc. %s',[pv.pwszVal]));
    if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Class, pv)) then
      Writeln(Format('Class        %s',[pv.pwszVal]));
    if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Manufacturer, pv)) then
      Writeln(Format('Manufacturer %s',[pv.pwszVal]));
end;

begin
 try
   ReportMemoryLeaksOnShutdown:=True;
   if (Win32MajorVersion >= 6) then  // available on Vista (or later)
   begin
    if Succeeded(CoInitializeEx(nil, COINIT_MULTITHREADED)) then
    try
     NotificationDemo;
    finally
      CoUninitialize;
    end;
   end
   else
   Writeln('Windows version not compatible');
 except
    on E:Exception do
        Writeln(E.Classname, ':', E.Message);
 end;
 Writeln('Press Enter to exit');
 Readln;
end.

This is the part 2 of the Exploring Delphi XE3 – WinApi Additions – Winapi.Functiondiscovery Article

One of the nice features of the Function Discovery API is the posibility of filter the results for device enumeration, for this you must use the CreateInstanceCollectionQuery method and then add the conditions for the query using the AddPropertyConstraint method.

Try this sample Delphi code which enumerates all the processors devices where the manufacturer is Intel.

{$APPTYPE CONSOLE}

{$R *.res}

uses
  System.Win.ComObj,
  Winapi.Windows,
  Winapi.Activex,
  Winapi.PropSys,
  Winapi.Functiondiscovery,
  System.SysUtils;

procedure Enumerate;
var
    LFunctionDiscovery : IFunctionDiscovery;
    LFunctionInstance  : IFunctionInstance;
    ppIFunctionInstanceCollection: IFunctionInstanceCollection;
    ppIFunctionInstanceCollectionQuery: IFunctionInstanceCollectionQuery;
    ppIPropertyStore  : IPropertyStore;
    pv : TPropVariant;
    pdwCount : DWORD;
    pszCategory: PWCHAR;
    hr : HResult;
    i : integer;
begin
  //create an instance to the  IFunctionDiscovery interface
  LFunctionDiscovery := CreateComObject(CLSID_FunctionDiscovery) as IFunctionDiscovery;
  try
    //set the provider to search
    pszCategory:=FCTN_CATEGORY_PNP;
    //get the devices collection
    hr := LFunctionDiscovery.CreateInstanceCollectionQuery(pszCategory, nil, false, nil, nil, ppIFunctionInstanceCollectionQuery);
      if Succeeded(hr)  then
      begin
       PropVariantClear(pv);
       pv.vt:=VT_LPWSTR;
       pv.pwszVal:='Intel';
       hr := ppIFunctionInstanceCollectionQuery.AddPropertyConstraint(PKEY_Device_Manufacturer, pv, QC_EQUALS);
       if not Succeeded(hr) then RaiseLastOSError;

       PropVariantClear(pv);
       pv.vt:=VT_LPWSTR;
       pv.pwszVal:='Processor';
       hr := ppIFunctionInstanceCollectionQuery.AddPropertyConstraint(PKEY_Device_Class, pv, QC_EQUALS);
       if not Succeeded(hr) then RaiseLastOSError;

        hr := ppIFunctionInstanceCollectionQuery.Execute(ppIFunctionInstanceCollection);
        if Succeeded(hr)  then
        begin
          //get the collection count
          ppIFunctionInstanceCollection.GetCount(pdwCount);
          if pdwCount=0 then
            Writeln(Format('No items was found for the %s category',[pszCategory]))
          else
          for i := 0 to pdwCount - 1 do begin
            //get the n Item of the collection
            if Succeeded(ppIFunctionInstanceCollection.Item(i, LFunctionInstance)) then
            begin
              //init the propertiess store
              LFunctionInstance.OpenPropertyStore(STGM_READ, ppIPropertyStore);
              //read the properties values
              if Succeeded(ppIPropertyStore.GetValue(PKEY_NAME, pv)) then
               Writeln(Format('Name          %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_InstanceId, pv)) then
               Writeln(Format('Instance Id   %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Driver, pv)) then
               Writeln(Format('Device Driver %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Model, pv)) then
               Writeln(Format('Model         %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Manufacturer, pv)) then
               Writeln(Format('Manufacturer  %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_LocationInfo, pv)) then
               Writeln(Format('Location      %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Class, pv)) then
               Writeln(Format('Class        %s',[pv.pwszVal]));
              if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_ClassGuid, pv)) then
               Writeln(Format('Class Guid   %s',[pv.puuid^.ToString]));
              Writeln;
            end
            else
             RaiseLastOSError;
           end;
        end;
      end
      else
       RaiseLastOSError;
  finally
    LFunctionDiscovery:=nil;
  end;
end;

begin
 try
   ReportMemoryLeaksOnShutdown:=True;
   if (Win32MajorVersion >= 6) then  // available on Vista (or later)
   begin
    if Succeeded(CoInitializeEx(nil, COINIT_MULTITHREADED)) then
    try
     Enumerate;
    finally
      CoUninitialize;
    end;
   end
   else
   Writeln('Windows version not compatible');
 except
    on E:Exception do
        Writeln(E.Classname, ':', E.Message);
 end;
 Writeln('Press Enter to exit');
 Readln;
end.

Starting with Windows Vista The SetupDi and the WMI are not longer the only APIs to enumerate devices and receive notifications about hardware changes, with the introduction of the Function Discovery API you can access the installed devices using a unified API and interfaces for gathering functionality, properties, and notifications from various device types like PnP, PnP-X, Registry, NetBIOS and custom (third-party) providers.

Delphi XE3 include the translation of the headers for the Function Discovery API in the Winapi.Functiondiscovery unit. In this post I will show the basic code to enumerate the hardware devices.

To get a collection of the devices (function instances), you must use use the IFunctionDiscovery.GetInstanceCollection method. from here to get each function instance in the collection in order, use the IFunctionInstanceCollection.Item method and finally use the IFunctionInstance.OpenPropertyStore and IPropertyStore.GetValue methods to retrieve the value of each property.

{$APPTYPE CONSOLE}

{$R *.res}

uses
  System.Win.ComObj,
  Winapi.Windows,
  Winapi.Activex,
  Winapi.PropSys,
  Winapi.Functiondiscovery,
  System.SysUtils;

procedure Enumerate;
var
    LFunctionDiscovery : IFunctionDiscovery;
    hr : HResult;
    i : integer;
    LFunctionInstance : IFunctionInstance;
    ppIFunctionInstanceCollection : IFunctionInstanceCollection;
    ppIPropertyStore  : IPropertyStore;
    pv : TPropVariant;
    pdwCount : DWORD;
    pszCategory: PWCHAR;
begin
  //create an instance to the  IFunctionDiscovery interface
  LFunctionDiscovery := CreateComObject(CLSID_FunctionDiscovery) as IFunctionDiscovery;
  try
    //set the provider to search
    pszCategory:=FCTN_CATEGORY_PNP;
    //get the devices collection
    hr := LFunctionDiscovery.GetInstanceCollection(pszCategory, nil, true, ppIFunctionInstanceCollection);
      //get the collection count
      if Succeeded(hr) and Succeeded(ppIFunctionInstanceCollection.GetCount(pdwCount)) then
      begin
        if pdwCount=0 then
          Writeln(Format('No items was found for the %s category',[pszCategory]))
        else
        for i := 0 to pdwCount - 1 do begin
          //get the n Item of the collection
          if Succeeded(ppIFunctionInstanceCollection.Item(i, LFunctionInstance)) then
          begin
            //init the propertiess store
            LFunctionInstance.OpenPropertyStore(STGM_READ, ppIPropertyStore);
            //read the properties values
            if Succeeded(ppIPropertyStore.GetValue(PKEY_NAME, pv)) then
             Writeln(Format('Name          %s',[pv.pwszVal]));
            if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_InstanceId, pv)) then
             Writeln(Format('Instance Id   %s',[pv.pwszVal]));
            if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Driver, pv)) then
             Writeln(Format('Device Driver %s',[pv.pwszVal]));
            if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Model, pv)) then
             Writeln(Format('Model         %s',[pv.pwszVal]));
            if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_Manufacturer, pv)) then
             Writeln(Format('Manufacturer  %s',[pv.pwszVal]));
            if Succeeded(ppIPropertyStore.GetValue(PKEY_Device_LocationInfo, pv)) then
             Writeln(Format('Location      %s',[pv.pwszVal]));
            Writeln;
          end
          else
           RaiseLastOSError;
        end;
      end
      else
       RaiseLastOSError;
  finally
    LFunctionDiscovery:=nil;
  end;
end;

begin
 try
   if (Win32MajorVersion >= 6) then  // available on Vista (or later)
   begin
    if Succeeded(CoInitializeEx(nil, COINIT_MULTITHREADED)) then
    try
     Enumerate;
    finally
      CoUninitialize;
    end;
   end
   else
   Writeln('Windows version not compatible');
 except
    on E:Exception do
        Writeln(E.Classname, ':', E.Message);
 end;
 Writeln('Press Enter to exit');
 Readln;
end.

As you can see the code is very straightforward, Now the next sample show how retrieves all the properties of each device.

{$APPTYPE CONSOLE}

{$R *.res}

uses
  System.Win.ComObj,
  Winapi.Windows,
  Winapi.Activex,
  Winapi.PropSys,
  Winapi.Functiondiscovery,
  System.Generics.Collections,
  System.SysUtils;

procedure Enumerate2;
var
    LFunctionDiscovery : IFunctionDiscovery;
    hr : HResult;
    i,j : integer;
    LFunctionInstance : IFunctionInstance;
    ppIFunctionInstanceCollection : IFunctionInstanceCollection;
    ppIPropertyStore  : IPropertyStore;
    pv : TPropVariant;
    pdwCount : DWORD;
    cProps: DWORD;
    pszCategory: PWCHAR;
    pkey: TPropertyKey;
    ListKeys : TDictionary<TPropertyKey, string>;
    KeyName : string;
begin
  //create a list with TPropertyKey descriptions
  ListKeys:=TDictionary<TPropertyKey, string>.Create;
  try
    ListKeys.Add(PKEY_NAME, 'Name');
{ Device properties }
{ These PKEYs correspond to the old setupapi SPDRP_XXX properties }
    ListKeys.Add(PKEY_Device_DeviceDesc, 'Device Desc');
    ListKeys.Add(PKEY_Device_HardwareIds, 'Hardware Id');
    ListKeys.Add(PKEY_Device_CompatibleIds, 'Compatible Id');
    ListKeys.Add(PKEY_Device_Service, 'Device Service');
    ListKeys.Add(PKEY_Device_Class, 'Class');
    ListKeys.Add(PKEY_Device_ClassGuid, 'Class GUID');
    ListKeys.Add(PKEY_Device_ConfigFlags, 'ConfigFlags');
    ListKeys.Add(PKEY_Device_Manufacturer, 'Manufacturer');
    ListKeys.Add(PKEY_Device_FriendlyName, 'Friendly Name');
    ListKeys.Add(PKEY_Device_LocationInfo, 'Location Info');
    ListKeys.Add(PKEY_Device_PDOName, 'PDO Name');
    ListKeys.Add(PKEY_Device_Capabilities, 'Capabilities');
    ListKeys.Add(PKEY_Device_UINumber, 'UI Number');
    ListKeys.Add(PKEY_Device_UpperFilters, 'Upper Filters');
    ListKeys.Add(PKEY_Device_LowerFilters, 'Lower Filters');
    ListKeys.Add(PKEY_Device_BusTypeGuid, 'Bus Type Guid');
    ListKeys.Add(PKEY_Device_LegacyBusType, 'Legacy Bus Type');
    ListKeys.Add(PKEY_Device_BusNumber, 'Bus Number');
    ListKeys.Add(PKEY_Device_EnumeratorName, 'Enumerator Name');
    ListKeys.Add(PKEY_Device_Security, 'Security');
    ListKeys.Add(PKEY_Device_SecuritySDS, 'Security SDS');
    ListKeys.Add(PKEY_Device_DevType, 'Dev Type');
    ListKeys.Add(PKEY_Device_Exclusive, 'Exclusive');
    ListKeys.Add(PKEY_Device_Characteristics, 'Characteristics');
    ListKeys.Add(PKEY_Device_Address, 'Address');
    ListKeys.Add(PKEY_Device_UINumberDescFormat, 'UI Number Desc. Format');
    ListKeys.Add(PKEY_Device_PowerData, 'Power Data');
    ListKeys.Add(PKEY_Device_RemovalPolicy, 'Removal Policy');
    ListKeys.Add(PKEY_Device_RemovalPolicyDefault, 'Removal Policy Default');
    ListKeys.Add(PKEY_Device_RemovalPolicyOverride, 'Removal Policy Override');
    ListKeys.Add(PKEY_Device_InstallState, 'Install State');
    ListKeys.Add(PKEY_Device_LocationPaths, 'Location Paths');
    ListKeys.Add(PKEY_Device_BaseContainerId, 'BaseContainer Id');
{ Device properties }
{ These PKEYs correspond to a device's status and problem code }

    ListKeys.Add(PKEY_Device_DevNodeStatus, 'Dev Node Status');
    ListKeys.Add(PKEY_Device_ProblemCode, 'Problem Code');
{ Device properties }
{ These PKEYs correspond to device relations }

    ListKeys.Add(PKEY_Device_EjectionRelations, 'Ejection Relations');
    ListKeys.Add(PKEY_Device_RemovalRelations, 'Removal Relations');
    ListKeys.Add(PKEY_Device_PowerRelations, 'Power Relations');
    ListKeys.Add(PKEY_Device_BusRelations, 'Bus Relations');
    ListKeys.Add(PKEY_Device_Parent, 'Parent');
    ListKeys.Add(PKEY_Device_Children, 'Children');
    ListKeys.Add(PKEY_Device_Siblings, 'Sibling');
    ListKeys.Add(PKEY_Device_TransportRelations, 'Transport Relations');
{ Other Device properties }
    ListKeys.Add(PKEY_Device_Reported, 'Reported');
    ListKeys.Add(PKEY_Device_Legacy, 'Legacy');
    ListKeys.Add(PKEY_Device_InstanceId, 'Instance Id');
    ListKeys.Add(PKEY_Device_ContainerId, 'Container Id');
    ListKeys.Add(PKEY_Device_ModelId, 'Model Id');
    ListKeys.Add(PKEY_Device_FriendlyNameAttributes, 'Friendly Name Attributes');
    ListKeys.Add(PKEY_Device_ManufacturerAttributes, 'Manufacturer Attributes');
    ListKeys.Add(PKEY_Device_PresenceNotForDevice, 'Presence Not For Device');
    ListKeys.Add(PKEY_Numa_Proximity_Domain, 'Numa Proximity Domain');
    ListKeys.Add(PKEY_Device_DHP_Rebalance_Policy, 'DHP Rebalance Policy');
    ListKeys.Add(PKEY_Device_Numa_Node, 'Numa Node');
    ListKeys.Add(PKEY_Device_BusReportedDeviceDesc, 'Bus Reported Device Desc');
    ListKeys.Add(PKEY_Device_InstallInProgress, 'Install In Progress');
{ Device driver properties }
    ListKeys.Add(PKEY_Device_DriverDate, 'Driver Date');
    ListKeys.Add(PKEY_Device_DriverVersion, 'Driver Version');
    ListKeys.Add(PKEY_Device_DriverDesc, 'Driver Desc');
    ListKeys.Add(PKEY_Device_DriverInfPath, 'Driver Inf Path');
    ListKeys.Add(PKEY_Device_DriverInfSection, 'Driver Inf Section');
    ListKeys.Add(PKEY_Device_DriverInfSectionExt, 'Driver Inf Section Ext');
    ListKeys.Add(PKEY_Device_MatchingDeviceId, 'Matching DeviceId');
    ListKeys.Add(PKEY_Device_DriverProvider, 'Driver Provider');
    ListKeys.Add(PKEY_Device_DriverPropPageProvider, 'Driver Prop Page Provider');
    ListKeys.Add(PKEY_Device_DriverCoInstallers, 'Driver CoInstallers');
    ListKeys.Add(PKEY_Device_ResourcePickerTags, 'Resource Picker Tags');
    ListKeys.Add(PKEY_Device_ResourcePickerExceptions, 'Resource Picker Exceptions');
    ListKeys.Add(PKEY_Device_DriverRank, 'Driver Rank');
    ListKeys.Add(PKEY_Device_DriverLogoLevel, 'Driver Logo Level');
    ListKeys.Add(PKEY_Device_NoConnectSound, 'No Connect Sound');
    ListKeys.Add(PKEY_Device_GenericDriverInstalled, 'Generic Driver Installed');
    ListKeys.Add(PKEY_Device_AdditionalSoftwareRequested, 'Additional Software Requested');
{Add more TPropertyKey here}

      //create a instance for the IFunctionDiscovery interface
      LFunctionDiscovery := CreateComObject(CLSID_FunctionDiscovery) as IFunctionDiscovery;
      try
        //set the provider
        pszCategory:=FCTN_CATEGORY_PNP;
        //get all the instances for the current provider
        hr := LFunctionDiscovery.GetInstanceCollection(pszCategory, nil, true, ppIFunctionInstanceCollection);
        if Succeeded(hr) then
          if Succeeded(ppIFunctionInstanceCollection.GetCount(pdwCount)) then
          begin
            if pdwCount=0 then
              Writeln(Format('No items was found for the %s category',[pszCategory]))
            else
            for i := 0 to pdwCount - 1 do begin
              if Succeeded(ppIFunctionInstanceCollection.Item(i, LFunctionInstance)) then
              begin
                //open the properties
                if Succeeded(LFunctionInstance.OpenPropertyStore(STGM_READ, ppIPropertyStore)) then
                begin
                   //get the num of properties for the current instance
                   ppIPropertyStore.GetCount(cProps);
                   for j := 0 to cProps - 1 do
                   begin
                      //get the TPropertyKey for the current index
                     if Succeeded(ppIPropertyStore.GetAt(j, pkey)) then
                      // get the value for the curent  TPropertyKey
                      if Succeeded(ppIPropertyStore.GetValue(pkey, pv)) then
                      begin
                       //resolves the key description or use the TGUID if is not found
                       KeyName:=pkey.fmtid.ToString;
                       if ListKeys.ContainsKey(pkey) then
                         KeyName:=ListKeys.Items[pkey];

                       //depending of the type of the property display the info
                       case pv.vt of
                         VT_BOOL    : Writeln(Format('%-40s %s',[KeyName , BoolToStr(pv.boolVal, True)]));
                         VT_UINT    : Writeln(Format('%-40s %d',[KeyName ,pv.ulVal]));
                         VT_INT     : Writeln(Format('%-40s %d',[KeyName ,pv.iVal]));
                         VT_I4,
                         VT_UI4     : Writeln(Format('%-40s %d',[KeyName ,pv.ulVal]));
                         VT_EMPTY   : Writeln(Format('%-40s %s',[KeyName ,'(Empty)']));
                         VT_LPWSTR  : Writeln(Format('%-40s %s',[KeyName ,pv.pwszVal]));
                         VT_CLSID   : Writeln(Format('%-40s %s',[KeyName ,pv.puuid^.ToString]));
                       else
                                    Writeln(Format('%-40s %s',[KeyName ,'(Type Unknow)']));
                       end;

                       PropVariantClear(pv);
                      end;
                   end;
                   Writeln;
                end;
              end
              else
               RaiseLastOSError;
            end;
          end
          else
           RaiseLastOSError
        else
         RaiseLastOSError;
      finally
        LFunctionDiscovery:=nil;
      end;
  finally
     ListKeys.Free;
  end;
end;


begin
 try
   if (Win32MajorVersion >= 6) then  // available on Vista (or later)
   begin
    if Succeeded(CoInitializeEx(nil, COINIT_MULTITHREADED)) then
    try
     Enumerate2;
    finally
      CoUninitialize;
    end;
   end
   else
   Writeln('Windows version not compatible');
 except
    on E:Exception do
        Writeln(E.Classname, ':', E.Message);
 end;
 Writeln('Press Enter to exit');
 Readln;
end.

This is just a basic sample of the use of the Function Discovery API, in the next post I will show another features of this API.
